Positioned proudly in our specialized Pet Bottle Servo Machine catalog, this unit incorporates a 30-ton clamping force, 35 kg high-pressure blowing pressure, and a solid 4000 KG build weight, ensuring immaculate wall consistency and flawless operational reliability across high-demand manufacturing floors.
Upgrade your facility with high-performance servo technology from J.P. Machinery. Contact our sales engineers via email today for detailed technical specifications and customized commercial proposals. Reach out to us at info2jpm@gmail.com to learn how our Pet Bottle Servo Machine lineup can transform your packaging capabilities.
Specifications of AUTOMATIC PET STRETCH BLOW MOULDING MACHINE Model: JP 1000 4B
Specification | Details |
|---|
Product Volume | 100ml - 1000ml |
Production Capacity BPH | 4800 - 5400 |
Working Air Pressure Kg/Cm2 | 35 kg |
Blowing Air Pressure Kg/Cm2 | 35 kg |
Clamping Force (Locking) Ton | 30 |
Air Consumption (Low Pressure) | - |
CFM High Pressure | 200 CFM |
Max Mould Opening Stock | 125 mm |
Mould Cavity No | 4 |
Mould Thickness mm | 160 mm |
Neck Diameter | 25-31 MM |
Operating | Servo & Pneumatic |
Heater Running Load | 24 KW |
Machine Weight | 4000 KG |
Heater Type | Infrared |
Chiller TR | 5 TR |
Length mm | 4400 mm |
Height mm | 3400 mm |
Width mm | 5600 mm |
Product Height mm | 285 mm |
Product Width mm | 90 mm |
Key Features of AUTOMATIC PET STRETCH BLOW MOULDING MACHINE Model: JP 1000 4B
Maximize precision and energy savings with our advanced Pet Bottle Servo Machine (Model 1000 4B Servo).
Exhaust Air Recovery System: Delivers additional savings of 15% on air consumption through an integrated recovery loop.
Fully Electric Motion Mechanics: Ensures high-speed operation, precise preform indexing, and minimal friction wear.
Massive 30-Ton Clamping Force: Provides robust mold locking stability required for high-speed 4-cavity servo production.
High-Pressure Blowing Integration: Equipped with 35 kg working and blowing air pressures for crisp container definition.
Robust Industrial Architecture: Built with a 4000 KG solid frame weight and 5 TR chiller compatibility for continuous runs.
These specialized technological features guarantee top-tier mechanical performance and flawless operational reliability.
Applications of AUTOMATIC PET STRETCH BLOW MOULDING MACHINE Model: JP 1000 4B
The JP 1000 4B Servo serves as a premier Pet Bottle Servo Machine choice for precise commercial packaging and automated bottling plants.
Premium Beverage Packaging: Ideal for high-speed automated moulding of mineral water and soft drink bottles.
Pharmaceutical Bottling: Crafts precise, sterile containers for liquid medicines and health syrups.
Cosmetic Product Packaging: Produces attractive, uniform bottles for shampoos, lotions, and liquid soaps.
Edible Oil Containers: Delivers high-clarity, rigid plastic bottles designed for culinary cooking oils.
Household Chemical Packaging: Molds robust, chemical-resistant containers for cleaning solutions.
Our advanced Pet Bottle Servo Machine systems ensure strict dimensional tolerances and exceptional visual appeal.
Why Choose Us for AUTOMATIC PET STRETCH BLOW MOULDING MACHINE Model: JP 1000 4B
Partner with J.P. Machinery, your trusted Pet Bottle Servo Machine manufacturer and industrial supplier, for cutting-edge automation, superior energy efficiency, and dedicated customer support.
Cutting-Edge Industrial Innovation: Incorporates the latest global automation trends into every design.
Superior Energy Efficiency: Servo mechanics consume significantly less power than standard hydraulic units.
Immaculate Output Consistency: Guarantees identical container weight and clarity across millions of units.
Dedicated Customer Service: Prompt troubleshooting, spare parts availability, and expert technical guidance.
Seamless Turnkey Integration: Coordinates effortlessly with downstream filling and capping lines.
Choosing our advanced Pet Bottle Servo Machine equipment ensures your plant stays ahead of market competitors through unmatched speed and reliability.
Contact Us
Get in touch with our engineering team today to discuss the JP 1000 4B Servo. Email J.P. Machinery directly at info2jpm@gmail.com to explore our complete Pet Bottle Servo Machine range for expert consultation and custom quotes.
